PS 50 F

products / PENDULUM SAWS

Product Description

PENDULUM SAWS
MACHINES FOR THE PACKAGING INDUSTRY

PS50F fixed head, designed to offer versatility and functionality in cutting all different types
of packaging material.
Thanks to a blade diameter 500 mm and a motor power of 5.5 kW allows you to cut
up to 145 mm thick and 510 mm wide.

Technical data


Blade diameter
500 mm
Blade rotation speed
2800 rpm

Blade motor power
kW 5 (HP 7,5) triphase

Max cutting capacity
510 mm (W) and 145 mm (H)

Blade feed system
manual

Extraction capacity
1250 m3/h

Extraction outlets
1 x Ø150 mm

Net weight
260 kg
