TR 601

products / CROSSCUT SAW WITH ASCENDING BLADE play video

Product Description

CUT OFF SAWS WITH ASCENDING BLADE
CLASSIC TOOLS FOR SAWING

TR601 is a cut off saw that was born out to meet the crosscutting needs of large industries.
Thanks to its robustness, a hydraulic saw unit drive with bimanual hand-saving control
to a motor power of 9 kW and a 600 mm diameter blade it can cut up to 200 mm thick and 650 mm wide.
Possibility of integrating the STROMAB STOP automatic measuring positioner for a semi-automatic cutting line.


Technical data


Blade diameter
600 mm
Blade rotation speed
3000 rpm
Blade motor power
kW 9 (HP 12,5) triphase

Max cutting capacity
650 mm (W) at 40 mm (H)
200 mm (H) at 300 mm (W)

Operating pressure
6-8 bar

Extracion outlets
2 x Ø100 mm

Boards loading
front and side

Net weight
780 kg

CUTTING DIAGRAM

STROMAB

the options that make the difference

CROSSCUT SAW WITH ASCENDING BLADE

STROMAB STOP

STROMAB STOP
