TR 450
products / CROSSCUT SAWS WITH ASCENDING BLADE
play video
Product Description
CUT OFF SAWS WITH ASCENDING BLADE
CLASSIC TOOLS FOR SAWING
TR450 is a cut off saw that was born out to meet the crosscutting needs of small and large industries.
Thanks to a pneumatic saw unit drive with bimanual hand-saving control, a motor power of 5,5 kW
Thanks to a pneumatic saw unit drive with bimanual hand-saving control, a motor power of 5,5 kW
and a 450 mm diameter blade it can cut up to 95 mm thick and 330 mm wide.
Possibility of integrating the STROMAB STOP automatic measuring positioner for a semi-automatic cutting line.
Possibility of integrating the STROMAB STOP automatic measuring positioner for a semi-automatic cutting line.
|
Technical data
|
|
|
Blade diameter
450 mm
|
Blade rotation speed
3000 rpm
|
|
Blade motor power
kW 5,5 (HP 7,5) triphase
|
Max cutting capacity
330 mm (W) at 25 mm (H)
95 mm (H) at 250 mm (W)
|
|
Operating pressure
6-8 bar
|
Extracion outlets
2 x Ø100 mm
|
|
Boards loading
from side
|
Net weight
340 kg
|
